IQM-233 Thin Film Deposition Controller PCI-Express Card
IQM-233 Thin Film Deposition Controller PCI-Express Card
제품 특징
- The IQM-233 PCI Express card turns your PC into a thin film deposition controller. This INFICON designed and manufactured product is the ideal choice for system OEMs, or anyone wishing to incorporate a thin film deposition controller into an existing PC or PLC controlled system. Installation is simple—all you need is an unoccupied PCI Express slot. IQM-233 is available to fit in standard or small form factor PC towers.
- UNPARALLELED FEATURES
- The IQM-233 features three QCM sensor inputs and three source outputs on each card. Up to two IQM-233 cards can be installed in a single PC (requires optional IQS-233 software), giving you a maximum of six sensor inputs and six source outputs. Only INFICON offers this level of flexibility in a fully integrated PC controlled QCM controller.
- IQM-233 is compatible with INFICON oscillator IPN 782-900-010, so replacing an SQM-242 card does not require a new oscillator. It is also compatible with all INFICON single and dual sensor heads.
- CHOOSE THE SOFTWARE SOLUTION RIGHT FOR YOU
제품 상세 정보
| 항목 | 값 |
|---|---|
| connector | No |
| managed | No |
| overview order | 1 |
| product order | 5 |
| product spec | Type : IQM-233
PC Interface : PCIe x1 - PCE Express Slot (Std or SFF) Sensor Inputs and Performance Sensor Inputs : 3 Connectors : SMA - Includes one SMA/BNC adapter Frequency Resolution (1) : ±0.10 Hz @ 6 MHz Measurement frequency range : - Adjustable : 4.0 MHz minimum, 6.1 MHz maximum Thickness and rate resolution/measurement (2) : ±0.12 Å Measurement interval : 0.1 to 2.0 s (adjustable) Outputs Source Outputs : 3 Connector : 15-pin high density D-sub Signal : 0 to +/- 10 V (dc) Resolution : 15 Bit Plus Sign Impedance : 50 Ω (1) Resolution given for 0.25 s measurement interval (2)Tooling/density = 100/1, fundamental frequency = 6 MHz, 0.25 s measurement interval |
| quantity | 0 |
| reg date | 2017-01-18 17:22:33 |
| single | No |
