Cool Drawer Single Sensor
Cool Drawer Single Sensor
제품 특징
- The Cool Drawer Single Sensors allow crystal installation into the sensor from the side, convenient for systems with insufficient room for front load crystal installation. The Cool Drawer Single Sensor employs the Cool Drawer Crystal Holder which is thermally shielded by the water-cooled housing insuring excellent crystal performance.
제품 상세 정보
| 항목 | 값 |
|---|---|
| connector | No |
| managed | No |
| overview order | 1 |
| product order | 3 |
| product spec | Type : Cool Drawer Single Sensor
Finish : Stainless steel, gold plated cool drawer Cooling Water : Minimum water flow of 150 to 200 cm³/min using 1/8 in. O.D. tube, 30°C max. (Do not allow to freeze) Electrical Connection : One standard female BNC on atmosphere side Crystal : Industry standard 0.550 in. diameter Air Supply : Shuttered sensors require 55 to 60 psi regulated 1 in. Bolt and Compression Fitting Terminations Materials : 304 stainless steel, Teflon®, ceramic, beryllium nickel, VITON® Temperature : Operational environment to 300° C with water cooling or 165° C without Mounting : 1.015 in. ±0.010 in. diameter aperture CF 40 Welded Terminations Materials : 304 stainless steel, Teflon, ceramic, beryllium nickel Temperature : Operational environment to 450° C with water cooling or 200° C without Mounting : Mates with 2 ¾ in. ConFlat type flanges with 1.375 in. I.D. min. |
