Cool Drawer Dual Sensor
Cool Drawer Dual Sensor
제품 특징
- The Cool Drawer Dual Sensor is designed for use in critical processes where it is desirable to have a second crystal in the vacuum chamber. Water cooled, cast stainless steel sensor body, two Cool Drawer crystal holders and a pneumatically actuated shutter provide for a rugged sensor head with the extra reliability of a backup crystal. A cleaner, more reliable vacuum system installation is possible as there are no coaxial cables inside the chamber.
제품 상세 정보
| 항목 | 값 |
|---|---|
| connector | No |
| managed | No |
| overview order | 1 |
| product order | 5 |
| product spec | Type : Cool Drawer Dual Sensor
Finish : Stainless steel, gold plated Cool Drawer™ Cooling water : Minimum water flow of 150 to 200 cm³/min using 1/8 in. O.D. tube, 30°C max. (Do not allow to freeze) Crystal : Industry standard 0.550 in. diameter Air supply : 55 to 60 PSI regulated Electrical connection : Two standard female BNCs on atmosphere side 1 in. bolt and compression fitting sealed terminations Materials : 304 stainless steel, Teflon®, ceramic, beryllium nickel, VITON® Temperature : Operational environment to 300° C with water cooling or 165° C without Mounting : 1.015 in. ±0.010 in. diameter aperture CF 40 welded terminations Materials : 304 stainless steel, ceramic, beryllium nickel Temperature : Operational environment to 450° C with water cooling or 200° C without Mounting : Mates with 2 ¾ in. ConFlat® type flanges |
| quantity | 0 |
| reg date | 2017-01-18 17:22:33 |
| single | No |
